| Supply voltage |
| Load voltage L+ |
| ● Rated value (DC) |
24 V |
| ● Reverse polarity protection |
Yes |
| Input current |
| from load voltage L+ (without load), max. |
30 mA |
| from backplane bus 5 V DC, max. |
50 mA |
| Power loss |
| Power loss, typ. |
1 W |
| Analog inputs |
| Number of analog inputs |
2 |
| ● For resistance measurement |
1 |
| permissible input voltage for voltage input (destruction limit), max. |
20 V; continuous; 75 V for max. 1 s (mark to space ratio 1:20) |
| permissible input current for current input (destruction limit), max. |
40 mA |
| Constant measurement current for resistance-type transmitter, typ. |
1.67 mA |
| Input ranges |
| ● Voltage |
Yes |
| ● Current |
Yes |
| ● Thermocouple |
Yes |
| ● Resistance thermometer |
Yes |
| ● Resistance |
Yes |
| Input ranges (rated values), voltages |
| ● 0 to +10 V |
No |
| ● 1 V to 5 V |
Yes |
| — Input resistance (1 V to 5 V) |
100 kΩ |
| ● 1 V to 10 V |
No |
| ● -1 V to +1 V |
Yes |
| — Input resistance (-1 V to +1 V) |
10 MΩ |
| ● -10 V to +10 V |
Yes |
| — Input resistance (-10 V to +10 V) |
100 kΩ |
| ● -2.5 V to +2.5 V |
Yes |
| — Input resistance (-2.5 V to +2.5 V) |
100 kΩ |
| ● -250 mV to +250 mV |
Yes |
| — Input resistance (-250 mV to +250 mV) |
10 MΩ |
| ● -5 V to +5 V |
Yes |
| — Input resistance (-5 V to +5 V) |
100 kΩ |
| ● -50 mV to +50 mV |
No |
| ● -500 mV to +500 mV |
Yes |
| — Input resistance (-500 mV to +500 mV) |
10 MΩ |
| ● -80 mV to +80 mV |
Yes |
| — Input resistance (-80 mV to +80 mV) |
10 MΩ |
| Input ranges (rated values), currents |
| ● 0 to 20 mA |
Yes |
| — Input resistance (0 to 20 mA) |
25 Ω |
| ● -10 mA to +10 mA |
Yes |
| — Input resistance (-10 mA to +10 mA) |
25 Ω |
| ● -20 mA to +20 mA |
Yes |
| — Input resistance (-20 mA to +20 mA) |
25 Ω |
| ● -3.2 mA to +3.2 mA |
Yes |
| — Input resistance (-3.2 mA to +3.2 mA) |
25 Ω |
| ● 4 mA to 20 mA |
Yes |
| — Input resistance (4 mA to 20 mA) |
25 Ω |
| Input ranges (rated values), thermocouples |
| ● Type B |
No |
| ● Type E |
Yes |
| — Input resistance (Type E) |
10 MΩ |
| ● Type J |
Yes |
| — Input resistance (type J) |
10 MΩ |
| ● Type K |
Yes |
| — Input resistance (Type K) |
10 MΩ |
| ● Type L |
No |
| ● Type N |
Yes |
| — Input resistance (Type N) |
10 MΩ |
| ● Type R |
No |
| ● Type S |
No |
| ● Type T |
No |
| ● Type U |
No |
| ● Type TXK/TXK(L) to GOST |
No |
| Input ranges (rated values), resistance thermometer |
| ● Cu 10 |
No |
| ● Ni 100 |
Yes |
| — Input resistance (Ni 100) |
10 MΩ; Standard |
| ● Ni 1000 |
No |
| ● LG-Ni 1000 |
No |
| ● Ni 120 |
No |
| ● Ni 200 |
No |
| ● Ni 500 |
No |
| ● Pt 100 |
Yes |
| — Input resistance (Pt 100) |
10 kΩ; Standard |
| ● Pt 1000 |
No |
| ● Pt 200 |
No |
| ● Pt 500 |
No |
| Input ranges (rated values), resistors |
| ● 0 to 150 ohms |
Yes |
| — Input resistance (0 to 150 ohms) |
10 MΩ |
| ● 0 to 300 ohms |
Yes |
| — Input resistance (0 to 300 ohms) |
10 MΩ |
| ● 0 to 600 ohms |
Yes |
| — Input resistance (0 to 600 ohms) |
10 MΩ |
| ● 0 to 6000 ohms |
No |
| Thermocouple (TC) |
| Temperature compensation |
| — parameterizable |
Yes |
| — internal temperature compensation |
Yes |
| — external temperature compensation with compensations socket |
Yes |
| — for definable comparison point temperature |
Yes |
| Characteristic linearization |
| ● parameterizable |
Yes |
| — for thermocouples |
Type E, J, K, L, N |
| — for resistance thermometer |
Pt100 (standard, climatic range), Ni100 (standard, climatic range) |
| Cable length |
| ● shielded, max. |
200 m; 50 m at 80 mV and thermocouples |
| Analog value generation for the inputs |
| Integration and conversion time/resolution per channel |
| ● Resolution with overrange (bit including sign), max. |
15 bit; Unipolar: 9/12/12/14 bit; bipolar: 9 bit + sign/12 bit + sign/12 bit + sign/14 bit + sign |
| ● Integration time, parameterizable |
Yes; 2,5 / 16,67 / 20 / 100 ms |
| ● Basic conversion time (ms) |
3 / 17 / 22 / 102 ms |
| ● Interference voltage suppression for interference frequency f1 in Hz |
400 / 60 / 50 / 10 Hz |
| Encoder |
| Connection of signal encoders |
| ● for voltage measurement |
Yes |
| ● for current measurement as 2-wire transducer |
Yes |
| ● for current measurement as 4-wire transducer |
Yes |
| ● for resistance measurement with two-wire connection |
Yes |
| ● for resistance measurement with three-wire connection |
Yes |
| ● for resistance measurement with four-wire connection |
Yes |
| Errors/accuracies |
| Operational error limit in overall temperature range |
| ● Voltage, relative to input range, (+/-) |
1 %; ±1% (80 mV); ±0.6% (250 mV to 1 000 mV); ±0.8% (2.5 V to 10 V) |
| ● Current, relative to input range, (+/-) |
0.7 %; From 3.2 to 20 mA |
| ● Resistance, relative to input range, (+/-) |
0.7 %; 150, 300, 600 Ohm |
| ● Resistance thermometer, relative to input range, (+/-) |
0.7 %; ±0.7 % (Pt100/ Ni100); ±0.8 % (Pt100 climate) |
| ● Thermocouple, relative to input range, (+/-) |
1.1 %; Type E, J, K, L, N |
| Basic error limit (operational limit at 25 °C) |
| ● Voltage, relative to input range, (+/-) |
0.6 %; ±0.6% (80 mV, 2.5 V to 10 V); ±0.4% (250 mV to 1 000 mV) |
| ● Current, relative to input range, (+/-) |
0.5 %; 3.2 to 20 mA |
| ● Resistance, relative to input range, (+/-) |
0.5 %; 150, 300, 600 Ohm |
| ● Resistance thermometer, relative to input range, (+/-) |
0.6 %; ±0.5% (Pt100/ Ni100), ±0.6% (Pt100 climate) |
| ● Thermocouple, relative to input range, (+/-) |
0.7 %; Type E, N, J, K, L |
| Interrupts/diagnostics/status information |
| Diagnostics function |
Yes; Parameterizable |
| Alarms |
| ● Diagnostic alarm |
Yes |
| ● Limit value alarm |
Yes; Parameterizable, channel 0 |
| Diagnoses |
| ● Diagnostic information readable |
Yes |
| Diagnostics indication LED |
| ● Group error SF (red) |
Yes |
| Potential separation |
| Potential separation analog inputs |
| ● between the channels |
No |
| ● between the channels and backplane bus |
Yes |
| ● between the channels and the power supply of the electronics |
Yes; Not for 2-wire transmitters |
| Isolation |
| Isolation tested with |
500 V DC |
| connection method |
| required front connector |
20-pin |
| Dimensions |
| Width |
40 mm |
| Height |
125 mm |
| Depth |
120 mm |
| Weights |
| Weight, approx. |
250 g |
