| Processor |
Arm9™, 400 MHz |
| Number of cores |
1 |
| Flash memory |
slot for microSD card, 512 MB included (optionally expandable) |
| Main memory |
64 MB DDR2 RAM (not expandable) |
| 1-second UPS |
integrated (1 MB on microSD card) |
| Programming languages |
IEC 61131-3 |
| Web visualization |
yes |
| Online change |
yes |
| Up/down load code |
yes/yes |
| Interfaces |
1 x RJ45 10/100 Mbit/s, 1 x USB device (behind the front flap), 1 x bus interface |
| Cooling |
passive |
| Bus interface |
D-sub connector, 9-pin according to CANopen specification, galvanically decoupled |
| Diagnostics LED |
1 x TC status, 2 x bus status |
| Clock |
internal battery-backed clock for time and date (battery behind the front flap, exchangeable) |
| Operating system |
Windows Embedded CE 6 |
| Control software |
TwinCAT 2 PLC |
| I/O connection |
E-bus or K-bus, automatic recognition |
| Power supply |
24 V DC (-15%/+20%) |
| UPS OCT-capable |
no |
| Current supply E-bus/K-bus |
2 A |
| Web-based management |
yes |
| Max. power consumption |
3 W |
| Max. power consumption E-bus/K-bus |
10 W (5 V/max. 2 A) |
| Dimensions (W x H x D) |
64 mm x 100 mm x 73 mm |
| Weight |
approx. 180 g |
| Operating temperature |
0…55°C |
| Storage temperature |
-25…+85°C |
| Relative humidity |
95%, no condensation |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating |
IP20 |
| Approvals/markings |
CE, UL, ATEX, IECEx, cFMus |
| Ex marking |
ATEX:
II 3 G Ex nA IIC T4 Gc
II 3 D Ex tc IIIC T135 °C Dc
IECEx:
Ex nA IIC T4 Gc
Ex tc IIIC T135 °C Dc
cFMus:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2, AEx ec IIC T4 Gc |
