| Processor |
Arm® Cortex®-A53, 1.2 GHz |
| Number of cores |
2 |
| Flash memory |
slot for microSD card, card not included (requires a microSD card with a minimum capacity of 16 GB) |
| Main memory |
1 GB LPDDR4 RAM (not expandable) |
| 1-second UPS |
integrated (1 MB on microSD card) |
| Interfaces |
1 x RJ45 10/100/1000 Mbit/s, 1 x USB 3.0, 1 x bus interface |
| Cooling |
passive |
| Bus interface |
2 x Ethernet RJ45 (switched, 10/100/1000 Mbit/s), optionally PROFINET (TF627x), EtherNet/IP™ (TF628x), BACnet/IP (TF8020) |
| Diagnostics LED |
1 x TC status, 1 x WD, 1 x error |
| Clock |
internal, capacitor-buffered real-time clock for time and date (storage capacity > 21 days) |
| Operating system |
Beckhoff RT Linux® |
| Control software |
TwinCAT 3 runtime (XAR) from TwinCAT 3.1 Build 4026 (XAE) |
| I/O connection |
E-bus or K-bus, automatic recognition |
| Power supply |
24 V DC (-15%/+20%) |
| UPS OCT-capable |
no |
| Current supply E-bus/K-bus |
2 A |
| Max. power consumption |
4 W |
| Max. power consumption (with loading UPS) |
7.5 W |
| Max. power consumption E-bus/K-bus |
10 W (5 V/max. 2 A) |
| Dimensions (W x H x D) |
71 mm x 100 mm x 73 mm |
| Weight |
approx. 220 g |
| Operating temperature |
-25…+60°C |
| Storage temperature |
-40…+85°C |
| Relative humidity |
95%, no condensation |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating |
IP20 |
| Approvals/markings |
CE, UL |
| TwinCAT 3 platform level |
Economy (20); please see here for an overview of all the TwinCAT 3 platform level |
