| Processor |
Arm® Cortex®-A8, 1 GHz |
| Number of cores |
1 |
| Flash memory |
2 x slot for microSD card, 512 MB included (optionally expandable) |
| Main memory |
1 GB DDR3 RAM (not expandable) |
| Interfaces |
2 x RJ45 10/100 Mbit/s (internal switch), 1 x DVI-D, 4 x USB 2.0, 1 x optional interface |
| Cooling |
passive |
| Diagnostics LED |
1 x power, 1 x TC status, 2 x flash access, 2 x bus status |
| Clock |
internal battery-backed clock for time and date (battery exchangeable) |
| Operating system |
Windows Embedded Compact 7, English |
| Control software |
TwinCAT 2 runtime
TwinCAT 3 runtime (XAR) |
| I/O connection |
E-bus or K-bus, automatic recognition |
| Power supply |
24 V DC (-15%/+20%) |
| UPS OCT-capable |
no |
| NOVRAM |
128 kB |
| Current supply E-bus/K-bus |
2 A |
| Max. power consumption |
5 W |
| Max. power consumption (with loading UPS) |
9 W |
| Max. power consumption E-bus/K-bus |
10 W (5 V/max. 2 A) |
| Weight |
approx. 590 g |
| Dimensions (W x H x D) |
84 mm x 100 mm x 91 mm |
| Relative humidity |
95%, no condensation |
| Operating temperature |
-25…+60°C |
| Storage temperature |
-40…+85°C |
| Vibration/shock resistance |
conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission |
conforms to EN 61000-6-2/EN 61000-6-4 |
| Protection rating |
IP20 |
| Approvals/markings |
CE, UL, DNV, with CX2900-0107 ordering option: ATEX, IECEx, cFMus |
| Ex marking |
ATEX:
II 3 G Ex nA IIC T4 Gc
II 3 D Ex tc IIIC T135 °C Dc
IECEx:
Ex nA IIC T4 Gc
Ex tc IIIC T135 °C Dc
cFMus:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2, AEx ec IIC T4 Gc |
| TwinCAT 3 platform level |
Economy Plus (30); please see here for an overview of all the TwinCAT 3 platform level |
